Buy Plywood Rack – CNC DXF File (2440x1220x2400mm Full-Sheet Rack)

Build a Full-Height Storage Rack From a Single Sheet of Plywood

This DXF file gives you everything you need to cut a sturdy, full-height 2440 x 1220 x 2400mm storage rack directly from standard plywood sheets on your CNC router. Designed for efficient nesting and minimal waste, this is a commercial-grade rack solution you can produce repeatedly and profitably.

Whether you're outfitting a workshop, warehouse, garage, or retail space, this rack design delivers a clean, professional result with no specialist joinery skills required — just load the file, run your CNC, and assemble.

What You'll Get

• 1 x DXF file (compatible with Vectric, Fusion 360, RhinoCAM, SheetCAM, and all major CAM software)
• Full-height rack design: 2440mm tall x 1220mm wide x 2440mm deep
• Optimised for standard full-sheet plywood (2440x1220mm)
• Flat-pack, tab-and-slot construction for easy assembly
• Instant digital download — no waiting, no shipping

Ideal For

• Workshop & garage storage builds
• Warehouse and retail shelving solutions
• CNC operators looking for repeatable, sellable furniture projects
• Makers and fabricators building to order

Compatible Materials

Designed for 18mm plywood. Can be adapted for MDF or other sheet materials of similar thickness.

Important Notes

• This is a digital download only. No physical product will be shipped.
• A CNC router and compatible CAM software are required to use this file.
• Tool paths are not included — assign your own in your CAM software.
• Assembly hardware (screws, bolts, or glue) not included.

Need a custom size or modification? Contact us before purchasing.

• Every part as closed DXF paths, nested on the sheet
• Opens in VCarve, Aspire, Fusion, Carbide Create and other DXF software

Files are licensed for your own use. You’re welcome to sell the pieces you cut, but please don’t share or resell the files.
