Plywood Display Rack DXF Design

Build a Display Stand From a Single Sheet of Plywood or MDF

This DXF file gives you everything you need to cut a sturdy, Display Stand 1000 x 1000 x 900 mm Display Stabs directly from standard plywood or MDF sheets on your CNC router. Designed for efficient nesting and minimal waste, this is a commercial-grade Display Stand solution you can produce repeatedly and profitably.

Whether you're outfitting a retail space, showroom, office, or workshop, this display design delivers a clean, professional result with no specialist joinery skills required — just load the file, load your tool paths and run your CNC, and assemble.

What You'll Get

• 1 x DXF file (compatible with Vectric, Fusion 360, RhinoCAM, SheetCAM, and all major CAM software)
• Display Stand design: 1000mm tall x 1000mm wide x 900mm deep
• Optimised for standard full-sheet plywood or MDF (2440x1220mm)
• Flat-pack, tab-and-slot construction for easy assembly
• Instant digital download — no waiting, no shipping

Ideal For

• Workshop & garage storage builds
• Warehouse and retail shelving solutions
• CNC operators looking for repeatable, sellable furniture projects
• Makers and fabricators building to order

Compatible Materials

Designed for 18mm plywood. Can be adapted for MDF or other sheet materials of similar thickness.

Important Notes

• This is a digital download only. No physical product will be shipped.
• A CNC router and compatible CAM software are required to use this file.
• Tool paths are not included — assign your own in your CAM software.
• Assembly hardware is not needed for this build.

Need a custom size or modification? Contact us before purchasing.
