Buy Chopping Board & Paddle – CNC DXF File (Mass Production Layout)

Mass-Produce Premium Chopping Boards & Paddles With Your CNC Router

This DXF file is purpose-built for high-volume production of chopping boards and serving paddles from full plywood sheets. Each board features engraved juice grooves for a professional finish, and the layout is optimised for maximum yield per sheet — making this an ideal file for end-of-year gifts, corporate giveaways, and branded merchandise runs.

The plywood construction delivers structural stability and natural resistance to warping, ensuring a consistent, quality result every time. Add your logo or a customer's name via engraving for a personalised product that commands a premium price.

What You'll Get

• 1 x DXF file containing both board profiles: rectangular chopping board (300x210mm) and paddle board (450x210mm)
• Juice groove engraving paths included on each board design
• Mass production nesting layout optimised for full plywood sheets
• Compatible with Vectric, Fusion 360, RhinoCAM, SheetCAM, and all major CAM software
• Instant digital download — no waiting, no shipping

Ideal For

• CNC operators producing branded gifts and corporate merchandise
• Makers selling at markets, pop-up shops, or online
• Woodworkers fulfilling bulk orders for restaurants, cafes, or events
• Anyone wanting a fast, repeatable, and profitable CNC project

Compatible Materials

Designed for 18mm plywood. Suitable for hardwood ply, bamboo ply, or food-safe MDF alternatives. Always finish with a food-safe oil or sealant before use.

CNC Setup Notes

• Import the DXF into your CAM software and assign the juice groove paths as an engraving pass first, then set up the profile cut paths.
• A strong vacuum bed is essential to hold boards securely during the cut programme.
• Recommended: 6mm or 8mm upcut spiral bit for profile cuts; V-bit or ball-nose for juice grooves.

Important Notes

• This is a digital download only. No physical product will be shipped.
• A CNC router and compatible CAM software are required to use this file.
• Tool paths are not included — assign your own in your CAM software.

Want a custom size, shape, or engraving layout? Contact us before purchasing.

• Every part as closed DXF paths, nested on the sheet
• Opens in VCarve, Aspire, Fusion, Carbide Create and other DXF software

Files are licensed for your own use. You’re welcome to sell the pieces you cut, but please don’t share or resell the files.
